SAKER IS THE WINNER OF THE 2023 ENGLISH OPEN F3F

AND 2023 WELSH OPEN F3F EVENTS.


I’m sure it won’t come a great surprise to many people that Ian Mason has been developing and testing a new 3m model.


There are more details about the model and it’s development on Ian’s blog   http://willowracing.blogspot.com/


The model is available in a Single layer and double layer light carbon layup, has an excellent finish and is very strong.


Saker Specifications

Wing span             3.00 m       118 in

Wing area              58.0 dm2   899 sq in

Length                   1.4 m          54.9 in

Flying weight from2392 g        84.4 oz

Wing loading         57.9 g/dm

Centre of Gravity95-100 mm from wing leading edge

ControlsAilerons, flaps, V tail


Saker double-Layer light Carbon Typical Weights

Left wing                734 g      25.8 oz

Right wing              736 g      25.9 oz

Fuselage                 301 g      10.6 oz

Tailplane                 96 g        3.3 oz

Wing joiner             117 g     4.1 oz

Ballast tube             48 g       1.7 oz

Accessories             38 g        1.3 oz

Total structure         2070 g    73   oz

Wiring                     30 g        1.1 oz

Receiver                   10 g       0.4 oz

Tail servos (2)          40 g        1.4 oz

Wing servos (4)       92 g        3.2 oz

Battery                   150 g        5.3 oz

Flying weight from   2392 g    84.4 oz


Recommended RC

V tail (servo body max 23 mm x 12 mm)

MKS HV6125e, MKS DS6125e, KST DS215MG, KST X12-508, KST MS320, Blue Bird BMS-106HV, Blue Bird BMS-107HV

Flap (servo max 12 mm thick)

MKS HBL6625, MKS HV6130, KST DS225, KST DS125, KST X10, Blue Bird A56V

Aileron (servo max 10 mm thick)

MKS HBL6625, MKS HV6130, KST DS225, KST DS125, KST X10, Blue Bird A56V, KST X08 Plus*, KST X08*

Receiver6 channel rx to match your transmitter

PowerOverlander 2S 1000mAh, Radient 1600 mAh 6V, HyperFlight 2200 mAh 4.8V, 1600 mAh 2S LiFe

*The supplied servo frames fit KST DS125 and X10 sized servos.
